4'' Ventilation Steel Inline Fan

Centrifugal tube fans provide a simple solution to boost or exhaust air uses include boosting air in duct work, exhausting air from a space and for hydroponics applications.
MOQ : 100 Sets

Send Inquiry

Fast Delievery
Quality Assurance
24/7 Customer Service

Product Introduction

Products Description

CDR series external rotor inline duct fan is a radial fan.This fan with compact structure, high capacity and easy installation, can resist high pressure and fit long pipeline operation while operating at low noise.

Our CDR series fan with moisture resistance, can be installed in moist environment. These fans should fit IP44 grade when being installed in the pipeline system.They cannot be used for conveying abrasive powder,soot and similar materials. The casing of this fan is steel, treatment is power coating.

Specification

Model	Rated Voltage (V)	Frequency (Hz)	Current (A)	Input Power (W)	Highest Speed (r/min)	Mamum Air Flow (m³/h)	Pressure (Pa)	Noise dB (A)
CDR2E-100	220/230	50	0.30	60	2650	350	320	47
CDR2E-100	110/230	60	0.65	70	2400	300	280	46
CDR2E-125	220/230	50	0.32	65	2650	490	295	47
CDR2E-125	110/120	60	0.68	72	2400	450	270	47
CDR2E-150	220/230	50	0.70	150	2600	800	360	52
CDR2E-150	110/120	60	1.60	170	2400	700	340	50
CDR2E-160	220/230	50	0.72	155	2600	900	340	52
CDR2E-160	110/120	60	1.65	170	2400	650	320	50
CDR2E-200	220/230	50	0.80	180	2550	1050	570	53
CDR2E-200	110/120	60	2.00	220	2500	1000	550	52
CDR2E-250	220/230	50	0.83	185	2550	1150	550	53
CDR2E-250	110/120	60	2.10	230	2500	1100	530	52
CDR2E-315	220/230	50	1.20	270	2600	1800	710	60
CDR2E-315	110/120	60	3.40	370	2600	1800	700	60
CDR2E315	220/230	50	1.90	400	2700	2300	800	65

Model	A	B	D	E	L	L1	W	W1	H
CDR2E-100	240	100	238	21	186	155	255	282.5	275
CDR2E-125	240	125	238	24	186	155	225	282.5	275
CDR2E-150	272	150	270	25	199	155	225	316	304
CDR2E-160	272	160	270	26	199	155	225	316	304
CDR2E-200	343	200	340	28	228	155	310	388	378
CDR2E-250	343	250	340	35	228	155	310	388	378
CDR2E-315	402	315	398	29	255	155	340	446	433

Detailed Images

Application

This fan is widely use for grow tent and greenhouse, also available for long-distance transmission of hotels, clubs, supermarkets, storerooms and restrooms and places which need low noise.

Company Profile

Sunshine Garden was founded in 2011, is one of earliest fabric pots and Smell proof bags manufacturer in China, We serve OEM and ODM customers from over 20 countries including USA, Canada, Europe, Japan and Australia. To meet fast growing of indoor garden and hydroponic needs, We are now added more products on our production line.

Our factory have over 10 years experence on making garden accessories and we have been engaged in export trade for years.If you are interested in any of our products please feel free to contact us. We are looking forward to establishing successful business, relationships with new clients around the world in the near future.

Every year our professinal staff will go abroad to participate in the exhibition,in many ways to show the advantage of our products.

FAQ

Q1:What can I do if we can not find the suitable fan model in the fan list?
Please contact us for customized fans.Please contact us for more information about our company and fans.

Q2: What information do you need to provide in order to get a quotation?
Generally, information about Size,Air Flow,Voltage of required fans is needed in order to select a right fan for you and provide you a quotation.

Q3: Can you tell me if this products can be made with USA electrical standard -- to work at 120V?
A: Yes For Sure we can make it work at 110V-120V.

Q4: Can we have the product with plug?
A: Yes, We can assembly with Plug that can be used in your country.

Q5.What is the samples fee ?
A.If you have freight collect express account such as UPS,FEDEX,we can send the sample for free(Special design will charge sample cost,and return after order).But if you haven't the account, we should ask the shipping charges..
Q6. What is your terms of packing?
A: Generally, we pack our goods in neutral woven bag. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q7. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q8. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Q9. How about your delivery time?
A: Generally, it will take 10 to 15 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q11.Can you customize the package and do you accept OEM ?
A.Yes , OEM is acceptable for us. We can print your logo on the box and pp bag
